Material (Recycled or First choice): PC/ABS, ABS, PS
For details see material data sheet
According to: DIN EN 60264-5-2
Capacity wire: up to 22,66 lbs
Winding volume: 1.287,8 in3
Plastic spool suitable both for high precision and random winding
The standard colour is black, available also in different colours
Weight: 1,27 lbs
All the stated dimensions, loads and weights are approximative values.
Usual tolerances for the sector and customers remain reserved
Possibility to customize the plastic spool
For the quality and features of the materials, see the specific data sheet
Transport and store in dry environments with temperatures from +41°F to +113°F
Before the use, let the goods acclimate at a temperature of 59°F
Handle avoiding collisions and/or falls
Pallets must not be stored in direct sunlight, because the heat increase may cause permanent warp of the plastic
Spools manufactured with plastic blend of PC/ABS are not suitable for winding Stainless Steel wires
To avoid the risk of Environmental Stress Cracking, it is strongly recommended to test the compatibility of the chemicals used in the production process with the material of the spool
