Material: coppered or uncoppered drawn steel wire.
For details see material data sheet.
Capacity welding wire: 15 kg - 18 kg - 22 kg - 27 kg .
Winding volume: from 3.922 to 4.767 cm3.
Suitable both for high precision and random winding. Upon request, it can be provided painted in different colours.
All the stated dimensions, loads and weights are approximative values.
Usual tolerances for the sector and customers remain reserved.
Possibility to customize the wire basket spool.
For the quality and features of the materials, see the specific data sheet.
Transportation and storage must be carried out in dry environments.
Before the use, let the goods acclimate at a temperature of 15°.
Handle avoiding collisions and/or falls.
| Full Mega Truck |
|---|
| 1360x248x300cm |
| pz/pallet = 260 |
| n. pallet = 46 |
| Tot pcs = 11960 |
| Pallet AxBxC=133X107X140H |
| Full Standard Truck |
|---|
| 1360x248x270cm |
| pz/pallet = 460 |
| n. pallet = 23 |
| Tot pcs = 10580 |
| Pallet AxBxC=133X107X248H |
| Full Container 20' Box |
|---|
| 586x231x236cm |
| pz/pallet = 400 |
| n. pallet = 10 |
| Tot pcs = 4000 |
| Pallet AxBxC=133X107X218H |
| Full Container 40' Box |
|---|
| 1200x230x236cm |
| pz/pallet = 400 |
| n.pallet = 21 |
| Tot pcs = 8400 |
| Pallet AxBxC=133X107X218H |
| Full Container 40' HC |
|---|
| 1200x234x268cm |
| pz/pallet = 460 |
| n. pallet = 21 |
| Tot pcs = 9660 |
| Pallet AxBxC=133X197X248H |
In order to guarantee the stability of the products during the transport, for long distances, we recommend to load a full truck/container.
In case of partial loads, secure the pallets carefully.
Upon request, there is the possibility to plan a full load of mixed products.
Upon request, there is the possibility to customize the pallet.
We suggest to manage our pallets in warehouse according to the FIFO method.
